Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Green Blinking The board functions
properly
Red Blinking The board is starting up
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On In active/standby mode or
load-sharing mode, the
board is active
- Off In active/standby mode,
the board is standby
Green Blinking In load-sharing mode, the
board is standby
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.6.6 H801SCUK Board Description
The H801SCUK board is a super control unit board. It is the core of the system control and
service switching and aggregation. The H801SCUK board can also function as the
management and control core of the integrated network management system (NMS). It
communicates with service boards about the key management and control information
through the master/slave serial port and inband GE/10GE channel. In this manner, the
H801SCUK board configures, manages, and controls the device, and also implements the
simple route protocol functions.
Functional Specifications
Please refer to "SCU boards Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
