Huawei SmartAX MA5600T Hardware Description

Specific
ations
H803SHDA H802SHLB H80ASHLM H802SHGM
Bonding Yes (M Pair
bonding)
Yes (M Pair and
EFM bonding )
Yes (M Pair,
EFM and IMA
bonding )
Yes (M Pair and
EFM bonding )
MELT No No Yes Yes
Annex
Type
G.991.2 ANNEX
A/B(does not
support
SHDSL.bis)
G.991.2 Annex
A/B (contains
F/G of
SHDSL.bis)
G.991.2 Annex
A/B (contains
F/G of
SHDSL.bis)
G.991.2 Annex
A/B (contains
F/G of
SHDSL.bis)
Matchin
g Cable
32-channel
subscriber cable
(old wire
sequence)
32-channel
subscriber cable
32-channel
subscriber cable
32-channel
subscriber cable
SHDSL
regenera
tors
manage
ment
No Yes Yes Yes
16-
TCPAM/
32-
TCPAM
Yes Yes Yes Yes
Modulati
on
configur
ation
No Yes(Supports
TCPAM16 and
TCPAM32)
Yes(Supports
TCPAM16 and
TCPAM32)
Yes
Connect
or
Champ 64-pin Champ 64-pin Champ 64-pin Champ 64-pin
3.24.2 H803SHDA Board Description
H803SHDA is a 16-port SHDSL service board. It board works with the SHDSL transceiver
unit-remote end (STU-R) to provide 16 channels of SHDSL access services.
Functional Specifications
Please refer to "SHDSL Service Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
745
