Figure 2-2 Appearance of the ETSI service subrack(xDSL)
2.1.2 Physical Specifications
This topic provides the dimensions, weight, and power consumption of the ETSI service
subrack.
Dimensions and Weight
Table 2-1 Specifications of the ETSI service subrack
Item
Specification
Dimensions (W x D x H, including
mounting ears)
530.00 mm x 275.80 mm x 447.20 mm
Dimensions (W x D x H, excluding
mounting ears)
490.00 mm x 275.80 mm x 447.20 mm
Maximum weight at full
configuration (including mounting
ears)
33.00 kg
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
71
