Huawei SmartAX MA5600T Hardware Description

Board
Name
Board Mapping
H801SCUB/
H802SCUB
H801SCU
F
H801SCU
L
H801SCUN/
H802SCUN/
H801SCUK
H801SCU
H
H801SCU
V
H801SPLL MA5600T ETSI service subrack, slots available for ADSL SPL boards are slots 1-8 and
11-18. In the MA5603T chassis, slots available for ADSL SPL boards are slots 0-5. ADSL
SPL boards and corresponding ADSL2+ service access boards are connected using intra-
subrack interconnection cables.
l When in the ETSI SPL subrack, ADSL SPL boards are generally installed in slots directly
under corresponding ADSL service boards. In the ETSI SPL subrack, slots available for
ADSL SPL boards are slots 1-8 and 11-18. ADSL SPL boards and corresponding ADSL2+
service access boards are connected using inter-subrack interconnection cables.
NOTE
For details about mapping between ADSL SPL boards and ADSL2+ service access boards, see 3.25.1
Differences Between ADSL SPL Boards.
H801SPPLA
H801SPPLB
H801SPPLC
H801SPPHA
H801SPPF1
H801SPPF
VDSL SPL board
H801VSTH
l VDSL SPL boards are installed in the MA5600T ETSI service subrack or MA5603T
chassis, generally in slots adjacent to corresponding VDSL2 service access boards. In the
MA5600T ETSI service subrack, slots available for VDSL SPL boards are slots 1-8 and
11-18. In the MA5603T chassis, slots available for VDSL SPL boards are slots 0-5. VDSL
SPL boards and corresponding VDSL2 service access boards are connected using intra-
subrack interconnection cables.
l When in the ETSI SPL subrack, VDSL SPL boards are generally installed in slots directly
under corresponding VDSL service boards. In the ETSI SPL subrack, slots available for
VDSL SPL boards are slots 1-8 and 11-18. VDSL SPL boards and corresponding VDSL2
service access boards are connected using inter-subrack interconnection cables.
NOTE
For details about mapping between VDSL SPL boards and VDSL2 service access boards, see 3.26.1
Differences Between VDSL SPL Boards.
H801VSTL
H801VSNF
H801VSNLA
H801VSPHA
H801VSPLA
H801VSPLC
SHDSL Extension board
H801SHET
l SHDSL extension boards are installed in the MA5600T ETSI service subrack or MA5603T
chassis, generally in slots adjacent to SHDSL service access boards. In the MA5600T ETSI
service subrack, slots available for SHDSL extension boards are slots 1-8 and 11-18. In the
MA5603T chassis, slots available for SHDSL extension boards are slots 0-5. SHDSL
extension boards and SHDSL service access boards are connected using intra-subrack
interconnection cables.
l When in the ETSI SPL subrack, SHDSL extension boards are generally installed in slots
directly under SHDSL service access boards. In the ETSI SPL subrack, slots available for
SHDSL extension boards are slots 1-8 and 11-18. SHDSL extension boards and SHDSL
service access boards are connected using inter-subrack interconnection cables.
3.5 Board Configuration(MA5608T)
This topic describes the type, name, slot and mapping of the boards supported by the
MA5608T.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
193
