X1 Pin Wire Color X2 Pin
8 Brown 8
7 White and brown 7
Technical Specifications
Specification
Description
Connector (X1/X2) RJ45 connector
Type Shielded straight-through network cable
Color Dark gray
Characteristic impedance 100.0 ohms
Wire diameter of the inner
conductor
0.530 mm
DC resistance of the inner
conductor
93.8 ohms/km
Number of wires 8
Frequency range 0-100 MHz
5.8 Local Maintenance Serial Cable
A local maintenance serial cable is used for debugging devices or maintaining devices at the
local end.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
5 Cable
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
904
