Appearance
Figure 2-9 Appearance of the IEC service subrack(xDSL)
2.3.2 Physical Specifications
This topic provides the dimensions, weight, and power consumption of the IEC service
subrack.
Dimensions and Weight
Table 2-13 Specifications of the IEC service subrack
Item
Specification
Dimensions (W x D x H, including
mounting ears)
482.60 mm × 275.80 mm × 441.70 mm
Dimensions (W x D x H, excluding
mounting ears)
442.00 mm × 275.80 mm × 441.70 mm
Maximum weight at full
configuration (including mounting
ears)
30.54 kg
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
89
