Huawei SmartAX MA5600T Hardware Description

Product Board
Type
Board
Name
Remarks Correspondin
g Outdoor
Cabinet
Terminals
MA5622A Control
board
HS22C
CVB
Supports SLV
only.
N/A
MA5623A Control
board
HS22C
CVW
Supports SLV
only.
N/A
MA5611S Integrate
d device
N/A Supports SLV
only.
N/A
MA5811S Integrate
d device
N/A Supports G.fast
Vectoring.
N/A
Table 3-150 SuperVector Hardware
Product
Board Type Board Name Remarks
MA5603T Control board SCUB
SCUN
SCUK
SCUN is recommended.
Backplane H802MABO None
VP board H806VPEF Installed in slot 12 fixedly.
SuperVector
board
H80DSDMM A 48-channel SuperVector
access service board.
H80DSDPM A 64-channel SuperVector
access service board.
H80DCSPE A 64-channel SuperVector
access service board.
3.23.2 H806VPEA Board Description
The H806VPEA board is a vectoring centralized processing board, and it works with the
vectoring-supporting VDSL2 board to achieve vectoring on the MA5603T. It provides the
clock source for the system and supports functions such as input and output of alarm digital
parameters.
Functional Specifications
The H806VPEA board supports the following functions and features:
l Seven inputs of alarm digital parameters and one output of digital controlling parameters
l Two inputs of 2 Mbit/s or 2 MHz BITS clock signals
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
727
