Name Color Status Meaning
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.8.3 H801GICE Board Description
The H801GICE board is a 4-port GE electrical interface card, providing upstream or
cascading electrical ports.
NOTE
As shown in Figure 3-25, the H801GICE board has the following changes after an upgrade from Ver.B
to Ver.C:
l The GE port indicators are changed.
Figure 3-25 Differences in appearance between Ver.B and Ver.C
Functional Specifications
Please refer to "Upstream Interface Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
262
