NOTE
The "upper" and "lower" in Table 3-163 and Table 3-164 refer to the physical location of ALM ports on
the front panel of the H806VPEF board.
3.23.4 H806VPGA Board Description
The H806VPGA board is a vectoring centralized processing board, and it works with
vectoring-supporting VDSL2 board to achieve vectoring on the MA5600T.
Functional Specifications
The H806VPGA board supports the following functions and features:
l Automatic power shutdown in case of a high temperature
l Working with the H802MABC and H803MABC backplane and the H806VPGA board
can be installed only in slots 8 and 11. When installed in slot 8, the H806VPGA board
processes the vectoring services of slots 1-6. When installed in slot 11, the H806VPGA
board processes the vectoring services of slots 13-18. Slots 7 and 12 cannot house
vectoring service boards but can house other service boards.
l G.993.5
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
741
