Table 6-29 Specifications of the EPS75-4815AF power system
Item Specification
Input
l Rated input voltage: 220 VAC (90 VAC to 290 VAC)
(Note that in the range of 90 VAC to 175 VAC, the
output current also decreases linearly, limited within a
specified range.)
l Maximum input current: 28 A
l Frequency: 50 Hz (45 Hz to 65 Hz)
Output
l Rated output voltage: -53.5 V DC
l Voltage range: -42 V DC to -58 V DC
l Output current:
– LOAD1: 10 A (circuit breaker)
– LOAD2: 30 A (circuit breaker)
– LOAD3: 40 A (circuit breaker)
– LOAD4: 40 A (circuit breaker)
– BATT.: 80 A (circuit breaker)
Efficiency ≥ 90% (in rated working state)
Working temperature range -33 °C to +65 °C.
NOTE
In the range of +50 °C to +65 °C, the output current decreases
linearly, limited within a specified range.
Cooling method Forced air cooling, with the built-in fan in the rectifier
module
Dimensions (W x D x H,
excluding the mounting
ears)
436 mm x 255 mm x 133 mm
6.6 GEPS4845 Power System
This topic describes the function, power supply principles, and front panel of the GEPS4845
power system, and provides the specifications of the GEPS4845 power system.
Function
The AC-powered cabinet uses the GEPS4845 power system to convert the 220/110 VAC into
-48 V DC and then distributes the power to each load. The GEPS4845 power system can
connect to two sets of batteries.
NOTE
Both the rectifier units of GEPS4845 and the two sets of batteries work in the load-balancing mode. The
rectifier units are hot backup for each other.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
942
