Huawei SmartAX MA5600T Hardware Description

Table 3-72 Pin assignments of the LINE port
Pin Signa
l
Pin Signa
l
Port Pin Signa
l
Pin Signa
l
64 TIP15 48 TIP7
133
3264
32 TIP16 16 TIP24
63 RING
15
47 RING
7
31 RING
16
15 RING
24
62 TIP14 46 TIP6 30 TIP17 14 TIP25
61 RING
14
45 RING
6
29 RING
17
13 RING
25
60 TIP13 44 TIP5 28 TIP18 12 TIP26
59 RING
13
43 RING
5
27 RING
18
11 RING
26
58 TIP12 42 TIP4 26 TIP19 10 TIP27
57 RING
12
41 RING
4
25 RING
19
9 RING
27
56 TIP11 40 TIP3 24 TIP20 8 TIP28
55 RING
11
39 RING
3
23 RING
20
7 RING
28
54 TIP10 38 TIP2 22 TIP21 6 TIP29
53 RING
10
37 RING
2
21 RING
21
5 RING
29
52 TIP9 36 TIP1 20 TIP22 4 TIP30
51 RING
9
35 RING
1
19 RING
22
3 RING
30
50 TIP8 34 TIP0 18 TIP23 2 TIP31
49 RING
8
33 RING
0
17 RING
23
1 RING
31
3.20.9 H802DSRE Board Description
The H802DSRE board is a 32-channel ISDN service board, providing 32 channels of ISDN
access services.
Feature and Specifications
Please refer to "Voice Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
499
