Table 3-21 Daughter board supported by the H801BIUA board
Daughter
Board
Function Remarks
CKMA Provides 32.768 MHz clock signals.
Traces the external reference source (8K
signals), and outputs the synchronized
32.768 MHz clock signals.
This daughter board
supports three working
modes: free-run, tracing,
and holdover.
3.9.3 H801CITA Board Description
H801CITA is a combo interface Transfer board that provides an ESC port.
Functional Specifications
The H801CITA board supports the following functions:
l Provides an ESC port for reporting various monitored information to the control board.
l Provides indicators for system alarms.
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
