Huawei SmartAX MA5600T Hardware Description

Standards Compliance of the 10G GPON Port
Standard ID Description
ITU-T G.987.1 10Gigabit-capable Passive Optical Networks (XG-PON)
General Requirements
ITU-T G.987.2 10Gigabit-capable Passive Optical Networks (XG-PON)
Physical Media Dependent (PMD) Layer Specification
ITU-T G.987.3 10Gigabit-capable Passive Optical Networks (XG-PON)
Transmission Convergence Layer Specification
ITU-T G.988 10Gigabit-capable Passive Optical Networks (XG-PON)
ONU Management and Control Interface Specification
4.3 GE Optical/Electrical Module
This topic describes the types, specifications, and relation between GE optical/electrical
modules and boards.
Table 4-4 shows the relation between GE optical/electrical modules and boards.
Table 4-4 Relation between GE optical/electrical modules and boards
Board Type
Board
Name
One-
channel
Two-fiber
Bi-
directional
GE Optical
Module
One-
channel
One-fiber
Bi-
directional
GE Optical
Module
Two-
channel
One-fiber
Bi-
directional
GE Optical
Module
One-channel
Two-fiber
Bi-
directional
GE CWDM
Optical
Module
GE Electrical
Module
Control
board
SCUB/
SCUN/
SCUK/
SCUF/
SCUH
√ √ × √ √
MCUD/
MCUD1/
MCUE
√ √ × √ √
Upstream
interface
board
GICF/
GICK/
X2CK/
H802X2CS
√ √ × √ √
GICD √ √ × √ √
GSCA √ √ × √ ×
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
849
