Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On This board is active
Yellow On This board works in the
load-balancing mode
- Off This board is standby
3.12.4 H801SPUC Board Description
The H801SPUC board is a service processing board, and it implements extended functions of
the OLT upstream interface. This board is mainly used in the Open Access scenario and is
used as an upstream interface board.
Functional Specifications
Please refer to "SPU Service Process Boards Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
335
