3. Using the special tool (09221-3F100 A/B) press-fit the valve guide. The valve guide must be press-fitted from
the upper side of the cylinder head. Keep in mind that the intake and exhaust valve guidesare different in
length.
4. After the valve guide is press-fitted, insert a new valve and check for proper clearance.
5. After the valve guide is replaced, check that the valve is fully seated. Recondition the valve seats as
necessary.
Do not install a valve guide unless it is oversize.
Replacing Valve Seat Ring
1. Cut away the inner face of the valve seat to reduce the wall thickness.
2. Enlarge the diameter of the valve seat so that it matches the specified hole diameter of the new valve seat
ring.
