TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Front Suspension System > Front
Lower Arm > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Front
Suspension System > Front Lower Arm > Repair procedures
1. Remove the front wheel.
2. Remove the driveshaft split pin, nut and washer.
3. Loosen the lower arm ball joint nut, but do not remove it.
4. Remove the strut lower mounting bolts(2).
5. Push the axle hub toward the outside to disconnect the driveshaft from the axle hub.
6. Using the special tool (09568 - 34000), disconnect the lower arm ball joint from the lower arm.
7. Temporarily install the strut lower mounting bolt.
8. Remove the lower arm bushing (A) and bushing (G) mounting bolts(2).
9. Remove the lower arm assembly.
1. Using a flat-tipped screwdriver, remove the dust cover from the lower arm ball joint.
2. Remove the snap ring.
3. Using a plastic hammer, tap the ball joint out of the lower arm.
