1. Disconnect the negative (-) battery terminal.
2. Remove the cluster housing after removing 2 screws.
3. Remove the 4 screws holding the cluster and remove the instrument cluster.
4. Installation is the reverse of removal.
1. Adjust the pressure of the tires to the specified level.
2. Drive the vehicle onto a speedometer tester. Use wheel chocks as appropriate.
3. Check if the speedometer indicator range is within the standard values.
Do not operate the clutch suddenly or increase/ decrease speed rapidly while testing.
Tire wear and tire over or under inflation will increase the indication error.
Velocity
(Km/h)
20 40 60 80 100 120 140
Tolerance
(Km/h)
20~24.4 40~43 60~64.4 80~85.5 100~105.5 120.5~126 140.5~146
Tolerance
(Km/h)
20~24.4 40~44.4 60~65.4 81~86.5 102~107.5 123~128.5 144~149.5
Velocity
(Km/h)
160 180 200 220 240 Area
