REMOVAL
1. Remove the wheel and tire.
2. Disconnect the brake hose.
3. Remove the cylinder mounting bolt.
4. Remove cylinder and pads.
5. Remove the caliper mounting bolts (2EA) from the knuckle.
6. Remove the caliper.
INSTALLATION
1. Install the pads and brake cylinder.
2. Install the brake hose to the caliper.
Bleeder screw tightening torque:
7~13 Nm (70~130 kgf·cm, 5.2~9.6 lbf·ft)
3. Fill the brake reservoir withe brake fluid.
4. Bleed the system.
DISASSEMBLY
1. Remove the piston boot.
2. Remove the piston using compressed air.
1. Do not put your fingers in front of the piston when using compressed air.
2. Be careful not to splatter the brake fluid.
