TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Brake System > Master Cylinder > Repair
procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Brake System > Master Cylinder
> Repair procedures
1. Remove the fluid level warning device connector.
2. Detach the brake tubes from the master cylinder, and then install the plug.
If there is any brake fluid on any painted surface, wash it off immediately.
3. Remove master cylinder mounting nuts and then lift out the master cylinder.
1. Install the master cylinder to the brake booster.
2. Install the booster and master cylinder to the dash panel.
3. Connect the brake tubes to the master cylinder.
4. Install the vacuum hose tightly.
5. Connect the operating rod to the brake pedal.
6. After filling the brake reservoir with the brake fluid, bleed the system.
Don't disassemble the brake booster.
1. Remove the reservoir cap and drain the brake fluid into a suitable container.
2. After disconnecting the mounting screws, pry the reservoir free from the master cylinder.
3. Using a snap ring pliers, remove the retainer ring.
