TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Brake System > Front Disc Brake > Repair
procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Brake System > Front Disc Brake
1. Remove the 2 guide pin bolt, remove the caliper assembly from the knuckle and secure it with a wire or some
other retaining method.
2. Remove the pads.
Do not depress the brake pedal while disassembling the pads.
1. Check the pads for wear or oil contamination and replace, if necessary.
The pads for the right and left wheels should be replaced at the same time. Never "drop" or intermix
brake pad sets.
All four pads must be replaced as a complete set.
When replacing the brake pad, check for deformation. When replacing the guide spring, use a new
one or the used one after cleaning away foreignmaterial.
2. Check the pad for damage or deformation.
Brake pad thickness:
Standard value: 11mm (0.43 in.)
Service limited value: 2mm (0.079 in.)
1. Install the pad clips.
2. Install the pads onto each pad clip.
