SPECIFICATIONS
Clutch operating method Hydraulic type
Clutch disc
- Type
- Facing diameter (Outside x Inside) mm (in.)
Single dry with diaphragm.
215 x 145 (8.5 x 5.7)
Clutch cover assembly
- Type
Diaphragm spring strap
Clutch release cylinder
* I.D. mm (in.)
2.0L : 19.05 (0.76)
2.7L : 20.64 (0.82)
Clutch master cylinder
* I.D. mm (in.)
15.87(0.62)
* I.D. : Inside Diameter
SERVICE STANDARD
Clutch pedal free play 6~13 mm (0.24~0.52 in.)
Clutch pedal height 166.9 mm (6.676 in.)
Clutch pedal stroke 2.0L : 145 mm (5.7 in.)
2.7L : 152 mm (6.1 in.)
Limit
Clutch disc rivet sink
Diaphragm spring end height difference
Clutch release cylinder clearance to piston
Clutch master cylinder clearance to piston
1.1 mm (0.044 in.)
0.5 mm (0.02 in.)
0.15 mm (0.006 in.)
0.15 mm (0.006 in.)
TIGHTENING TORQUE
Item Nm kg·cm lb·ft
Clutch pedal to pedal support member
(Clutch pedal bracket)
19~28 190~280 14~20
Clutch pedal support member to master cylinder 8~10 80~100 6~7
Clutch tube flare nut 13~17 130~170 9~13
Clutch tube bracket 4~6 40~60 3~4
Reservoir band 13~17 130~170 9~13
Clutch release cylinder 15~22 150~220 11~16
Clutch release cylinder union bolt 20~25 200~250 15~18
Clutch cover assembly
Single mass flywheel
Dual mass flywheel
15~22
20~27
150~220
200~270
11~16
14~19
LUBRICANTS
Items Specified lubricants Quantity
Contact surface of release bearing and fulcrum of
CASMOLY L 9508 As required
Page
1
of
2
24.04.2008
