Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Heating,Ventilation, Air Conditioning > Air conditioning
System > Triple pressure switch > Description and Operation, TIBURON(GK) > 2003 > G 2.7 V6 DOHC >
Heating,Ventilation, Air Conditioning > Air conditioning System > Triple pressure switch > Description
and Operation
DESCRIPTION
- Rating load : Inductive loacl DC 12V, 10~250mA
- Applicable voltage range : DC 8V ~ DC 16V
- Applicable temperature range : -30°C ~ 120°C
- Applicable refrigerant : R-134a
- Insulation resistance : Min. 100MΩ at DC 500V
Pressure ON OFF
High 32.0 ± 2.0 26.0 ± 2.0
Low 2.3 + 0.25 / -0.29 2.0 ± 0.2
Medium 18.0 ± 0.8 14.0 ± 1.2
LOW & HIGH
MEDIUM
Page
1
of
1
24.04.2008
