7. Using the special tool (09495-33100, 09517-29000), remove the wheel bearing outer race from the knuckle.
1. Check the hub for cracks and the splines for wear.
2. Check the brake disc for scoring and damage.
3. Check the knuckle for cracks.
4. Check the bearing for cracks or damage.
1. Apply multi-purpose grease to the contacting surface of the knuckle hub and bearing thinly.
2. Using the special tools (09495-33100, 09517-29000), press-in the bearing to the knuckle.
1. Press-in the outer race of the wheel bearing to prevent damage to the bearing assembly.
2. When installing a bearing assembly, always use a new one.
3. Install the dust cover.
4. Using the special tool (09495-33100), press-in the hub to the knuckle.
Press-in the inner race of the wheel bearing to prevent damage to the bearing assembly.
