1. Do not disassemble the birfield joint assembly.
2. Special grease must be applied to the driveshaft joint. Do not substitute with another type of grease.
3. The boot band should be replaced with a new one.
1. Remove the double offset joint boot bands and pull the double offset joint boot from the double offset joint
outer race.
Be careful not to damage the boot.
2. Remove the circlip with a flat-tipped screwdriver.
3. Pull out the driveshaft from the double offset joint outer race.
4. Remove the snap ring and take out the inner race, cage and balls as an assembly.
