Attach a chain or cable to the engine hooks and lift enough so that there is no pressure on the motor mounts.
Remove the front roll stopper bracket from the sub-frame.
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Engine Mechanical System > Cylinder Block > Engine Mounts
> Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Engine Mechanical System > Cylinder
Block > Engine Mounts > Repair procedures
REMOVAL
Engine Mounting
1. Remove the engine mounting insulator bolts.
2. Remove the engine mounting bracket from the engine.
Transaxle Mounting
1. Remove the transaxle mounting insulator bolts.
2. Remove the tranaxle mounting bracket from the transaxle.
Front Roll Stopper
Page
1
of
2
24.04.2008
