Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Heating,Ventilation, Air Conditioning > Heater > Temperature
Control Actuator > Description and Operation, TIBURON(GK) > 2003 > G 2.7 V6 DOHC >
Heating,Ventilation, Air Conditioning > Heater > Temperature Control Actuator > Description and
Operation
DESCRIPTION
- Operating temp. : -30°C ~ +80°C
- Operating voltage : DC 9V ~ 16V
- Rated voltage : DC 12V
- Rated load : 4kgf/cm
- Rated voltage : DC 12V
- Rated watt. : 0.25W (at 40°C)
- Opration volt : DC 5V ± 0.5V
- Total resistance : 5kΩ ± 10%
- Output lock torque : Min 1.76Nm (18kgf/cm) (at DC 12V)
- Rated AMP : Max. 150mA
- Lock vol. : Max. 400ma
- Characteristics
Page
1
of
1
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...
