BCM practices input/output actuation test with the hi-scan to find out input/output errors.
INPUT/OUTPUT MONITORING
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > Keyless Entry And >
Troubleshooting, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > Keyless Entry And
> Troubleshooting
TROUBLESHOOTING
INPUT / OUTPUT NAME DISPLAY CONDITION
POWER INPUT Battery voltage Voltage
INPUT Key warning switch
Key removal
Key insert
INPUT Accessory switch
OFF
ON
INPUT IGN1 switch
OFF
ON
INPUT IGN2 switch
OFF
ON
INPUT Alternator voltage Voltage
OUTPUT Start inhibitor
Enable
Disable
FLASHER
INPUT Turn signal switch (LH)
OFF
ON
INPUT Turn signal switch (RH)
OFF
ON
OUTPUT Turn signal lamp (LH)
OFF
ON
OUTPUT Turn signal lamp (RH)
OFF
ON
INPUT Hazard swtich
OFF
ON
INPUT Hazard detection current Current
LAMP
INPUT Tail lamp switch
OFF
ON
OUTPUT Tail lamp
OFF
ON
INPUT Head lamp switch
OFF
ON
INPUT Auto light area option
Domestic
Export
INPUT Auto light sensor Voltage
Control the head
lamp at the auto light
mode
OUTPUT Head lamp
OFF
ON
INPUT Front fog lamp switch
OFF
ON
INPUT Rear fog lamp switch
OFF
Page
1
of
5
24.04.2008
