14~17 Nm (140~170 kg·cm, 10.3~12.5 lb·ft)
5. Remove the rear wiper motor after removing 3 bolts, and disconnect the motor's connector.
INSTALLATION
1. Installation is the reverse of removal.
2. Set the washer nozzle on the specified spray position.
INSPECTION
1. Remove the connector from the rear wiper motor.
2. Connect battery positive (+) and negative (-) cables to terminals 3 and 4 respectively.
3. Check that the motor operates normally. Replace the motor if it operates abnormally.
Page
2
of
2
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...
