Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Front Suspension System > Front Strut
Assembly > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Front
Suspension System > Front Strut Assembly > Repair procedures
REMOVAL
1. Remove the front wheel.
2. Detach the brake hose bracket from the strut assembly.
Do not apply excessive force to the components.
3. Remove the stabilizer link.
4. Remove the strut upper mounting bolts(3).
5. Remove the strut assembly.
INSTALLATION
1. When installing the front strut, be sure to clear the conneting surface.
2. Install the strut assembly so the identification label on the strut insulator faces toward the inside of vehicle.
Page
1
of
4
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...
