5. Remove the power steering oil pump mounting bracket.
INSTALLATION
1. After installing the oil pump to the oil pump bracket, install the "V" belt and tighten the bolt adjusting tension to
the specified torque.
Standard value
Oil pump adjusting bolt
3.5~5.0 Nm (350~500 kg·cm, 25.8~37 lb·ft)
2. Install the suction hose.
Install the pressure hose to the oil pump, facing the painted part on the hose toward the oil pump.
3. Install the pressure hose to the oil pump.
