Hyundai Tiburon 2003 User Manual

When rotating the "215/45 ZR17" Tires, ensure to follow the "ROTATION" direction marked on the sidewall of tires
(see page SS-30).
TIGHTENING TORQUE
Items Nm kg·cm lb·ft
Wheel nut 90~110 900~1100 67~82
Driveshaft nut
2.0L
2.7L
200~260
200~280
2000~2600
2000~2800
148~192
148~207
Front strut upper installation nut 45~60 450~600 33~44
Front strut assembly to knuckle 140~160 1400~1600 104~118
Front strut mounting self-locking nut 40~50 400~500 29~37
Lower arm ball joint to knuckle 60~72 600~720 43~52
Lower arm bushing (A) mounting bolt 130~150 1300~1500 96~111
Lower arm bushing (G) mounting bolt 130~150 1300~1500 96~111
Stabilizer bar bracket mounting bolt 30~45 300~450 22~33
Tie rod end ball joint to knuckle 24~34 240~340 18~25
Tie rod end lock nut 50~55 500~550 37~41
Stabilizer link nut 35~45 350~450 26~33
Rear strut upper mounting nut 30~40 300~400 22~30
Rear strut lower mounting nut 110~130 1100~1300 81~96
Rear strut mounting self locking nut 40~60 400~600 30~44
Rear stabilizer link to stabilizer bar 35~45 350~450 26~33
Rear stabilizer bar bracket bolt 17~26 170~260 13~19
Rear suspension arm tie rod nut 50~60 500~600 37~43
Rear suspension arm (A,B) mounting bolt 160~180 1600~1800 118~133
Rear cross member mounting bolt 100~120 1000~1200 74~88
Trailing arm to bracket nut 40~50 400~500 30~37
Trailing arm bracket to body frame 40~50 400~500 30~37
Trailing arm mounting 100~120 1000~1200 74~88
Replace the self-locking nuts with new ones after removal.
LUBRICANTS
Recommended lubricant Quantity
In ball joint of lower arm Variant R-2 grease or poly lub gly 801K As required
