TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Heating,Ventilation, Air Conditioning > Heater > Mode Control
Actuator > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Heating,Ventilation, Air
Conditioning > Heater > Mode Control Actuator > Repair procedures
REPLACEMENT
1. Remove the 7P connector (A) from the mode actuator (B). Remove the self-tapping screws and the mode
actuator from the heater unit.
2. Install in the reverse order of removal. After installation, make sure the mode actuator runs smoothly.
