Hyundai Tiburon 2003 User Manual

13. Disconnect the wiring harness of the coolant sensor assembly.
INSTALLATION
1. Install the intake manifold and delivery pipe reversing the order of the removal procedure.
Tightening torque
Intake manifold :
19 ~ 21Nm (190 ~ 210kg.cm, 14 ~ 15lb.ft)
INSPECTION
SURGE TANK AND INTAKE MANIFOLD
1. Check the surge tank and intake manifold for damage, cracking or restriction of the vacuum outlet port, water
or gas passages.
Page
3
of
4
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...

Hyundai Tiburon 2003 Specifications

General

Brand	Hyundai
Model	Tiburon 2003
Category	Automobile
Language	English
