TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Front Suspension System > Front
Stabilizer Bar > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System >
Front Suspension System > Front Stabilizer Bar > Repair procedures
1. Remove the front wheel.
2. Remove the stabilizer link assembly.
3. Remove the stabilizer bracket and bushing
4. Remove the stabilizer bar.
1. Install the bushing on the stabilizer bar.
1) When installing the stabilizer bar, follow the identification color (ID color) as below.
ID : Identification
Model ID color Outer diameter
2.0L Sports
(HARD)
- 21.8mm (0.86 in.)
2.0L Normal
(SOFT)
White 18.8mm (0.74 in.)
2.7L Sports
(HARD)
Yellow 21.8mm (0.86 in.)
2.7 Normal
(SOFT)
Red 18.8mm (0.74 in.)
2) Position the bushing on the outside of the stabilizer bar clamp so as to install it.
