Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body (Interior and Exterior) > Seat Belt > rear seat belt >
Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body (Interior and Exterior) > Seat Belt >
rear seat belt > Repair procedures
REMOVAL AND INSTALLATION
1. Remove the mounting bolts from the rear seat cushion.
2. Remove the mounting bolts from the rear seat back.
3. Remove the rear seat back lower side mounting bracket.
Tightening torque:
40~55 Nm (400~500 kg·cm, 25~40 lb·ft)
4. Loosen the rear seat belt upper, lover mounting bolts, and remove the rear seat belt.
5. Installation is the reverse of removal.
Page
1
of
2
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...
