Install the pressure hose being careful so that it does not twist and come in contact with other
components.
4. Add power steering fluid (PSF-3).
5. Air bleed the system.
6. Check the oil pump pressure.
DISASSEMBLY
1. After removing the 2 bolts, remove the suction pipe and the O-ring from the oil pump body.
2. Loosen the four bolts and remove the oil pump cover assembly.
3. Remove the cam ring.
4. Remove the rotor and vanes.
5. Remove the oil pump side plate.
6. Remove the inner and outer O-ring.
7. Remove the side plate spring.
Page
3
of
8
24.04.2008
