1. Fully extend the shock absorber rod.
2. Drill a hole on the A section to remove gas from the cylinder.
The gas coming out is harmless, but be careful of chips that may fly when drilling.
Be sure to wear face shield and safety goggles.
1. Install lower spring pad so that the protrusions fit in the holes of the spring lower seat.
2. Install the dust cover on the shock absorber.
3. Using the special tools (09546-26000 or J38402), compress the coil spring.
After the spring is fully compressed, install it on the shock absorber.
Install the coil spring with the identification mark directed toward the knuckle.
4. After fully extending the piston rod, install the spring upper seat and insulator assembly.
Align the D-shaped hole in the spring seat upper assembly with the protrusion on the piston rod.
