2. Install the dust cover mounting plate.
3. Connect the dust cover to its mounting plate with a new strap.
4. Connect the steering gear box assembly to the steering column and shaft assembly.
5. Installation is the reverse of removal.
6. After installation, bleed the system.
DISASSEMBLY
1. Remove the tie rod end from the tie rod.
2. After mounting the tie rod end in a vise, remove the dust cover from the ball joint.
3. Remove the bellows band.
