driving If acceleration is poor even if downshifting
occurs while driving, the cause is probably a
malfunction of the engine system, brake or
clutch.
•
Malfunction of the brake of clutch
Malfunction while
driving
Vibration
If vibration occurs when driving at constant
speed or when accelerating and deceleration in
top range, the cause is probably abnormal
damper clutch pressure or a malfunction of the
engine system, damper clutch control solenoid
valve, torque converter or valve body.
•
Abnormal damper clutch pressure
•
Malfunction of the engine system
•
Malfunction of the damper clutch control
solenoid valve
•
Malfunction of the torque converter
•
Malfunction of the valve body
Transaxle range switch system
The cause is probably a malfunction of the inhibitor switch circuit,
ignition switch circuit or a defective TCM.
•
Malfunction of the transaxle range switch
•
Malfunction of the ignition switch
•
Malfunction of connector
•
Malfunction of the TCM
Idle position switch system
The cause is probably a defective idle position switch circuit, or a
defective TCM.
•
Malfunction of the idle position switch
•
Malfunction of connector
•
Malfunction of the TCM
Triple pressure switch system
The cause is probably a defective triple pressure switch circuit or a
defective TCM.
•
Malfunction of the triple pressure switch
•
Malfunction of connector
•
Malfunction of A/C system
•
Malfunction of the TCM
Vehicle speed sensor system
The cause is probably a defective vehicle speed sensor circuit or a
defective TCM.
•
Malfunction of the vehicle speed sensor
•
Malfunction of connector
•
Malfunction of the TCM
ELEMENTS IN USE IN EACH GEAR
Operating element
Underdrive
clutch (UD)
Reverse
clutch (REV)
Overdrive
clutch (OD)
Low-and
reverse
brake (LR)
Second
brake (2nd)
One way
clutch
(OWC) Selector lever position
P Parking - - - O - -
R Reverse - O - O - -
N Neutral - - - O - -
D
1st O - - O - O
2nd O - - - O -
3rd O - O - - -
4th - - O - O -
3
1st O - - O - O
2nd O - - - O -
3rd O - O - - -
2
1st O - - O - O
2nd O - - - O -
L 1st O - - O - O
OPERATING ELEMENTS AND THEIR FUNCTION
Operating element Code Function
Underdrive clutch UD Connects input shaft and underdrive sun gear
Reverse clutch REV Connects input shaft and reverse sun gear
Overdrive clutch OD Connects input shaft and overdrive planetary carrier
Page
10
of
11
24.04.2008
