3. Clean the spider assembly.
4. Remove the birfield joint boot bands and pull out the tripod joint boot and birfield joint boot.
If the boot is to be reused, wrap tape around the driveshaft splines to protect the boot.
REASSEMBLY
1. Wrap tape around the driveshaft splines (tripod joint side) to prevent damage to the boots.
2. Apply grease to the driveshaft and install the boots. (see page DS-3)
3. To install the dynamic damper, keep the B.J. and driveshaft in a straight line and secure the dynamic damper
with the dynamic damper band inthe direction illustrated.
4. Apply grease into the tripod joint boot and install the boot.
Tripod joint boot grease (gr.)
(2.0L A/T, 2.0 L 6M/T, 2.7L)
Page
6
of
8
24.04.2008
