TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Driveshaft and axle > Front Axle Assembly > Front Hub / Axle
> Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Driveshaft and axle > Front Axle
Assembly > Front Hub / Axle > Repair procedures
1. Remove the front wheel.
2. Remove the split pin and driveshaft nut from the front hub.
3. Remove the front brake assembly from the knuckle and suspend it with a wire.
4. Remove the vehicle speed sensor from the knuckle.
5. Disconnect the tie rod end ball joint from the knuckle by using the special tool (09568 - 34000).
Be sure to tie the special tool (09568 - 34000) to the near part with a cord not to fall.
6. Disconnect the strut assembly from the knuckle.
7. Disconnect the driveshaft from the hub.
8. Disconnect the lower arm ball joint from the knuckle by using the special tool (09568 - 34000).
9. Remove the hub and knuckle as an assembly.
To Next Page
