Place a piece of solder (approx. 10 mm in length, 3mm in diameter) on the torque converter housing as shown in the
figure.
Install the torque converter housing to the transmission case without applying sealant. Tighten its mounting bolts to the
specified torque. Loosen the bolts, and remove the solder. Use a micrometer to measure the thickness(T) of the pressed
solder. Select a spacer with a thickness that is within the following value.
Installing the underdrive clutch hub makes it easy to measure the underdrive sun gear end play.
DIFFERENTIAL CASE PRELOAD ADJUSTMENT
Standard value : (T + 0.045mm) to (T + 0.105mm)
