TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System > Rear Suspension System > Rear
Stabilizer Bar > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Suspension System >
Rear Suspension System > Rear Stabilizer Bar > Repair procedures
1. Remove the stabilizer bar link from the rear strut assembly.
2. Remove the rear stabilizer bar mounting brackets.
3. Remove the stabilizer bar.
1. Install the bushing on the stabilizer bar.
1) When installing the stabilizer bar, follow the identification color (ID color) as below.
Model ID color Outer diameter
GL/GLS Yellow 16.8mm (0.66 in.)
Sports/Top Green 17.8mm (0.70 in.)
2) After matching the bushing in the inside of the white painted part on the stabilizer bar, install the them.
2. Install the bracket on the bushing.
3. Tighten the components below to the specified torque as follows.
Rear stabilizer bar mounting bracket :
17~26 Nm (170~260 kgf·cm, 13~19 lbf·ft)
Rear stabilizer bar link mounting :
35~45 Nm (350~450 kgf·cm, 26~33 lbf·ft)
