Hyundai Tiburon 2003 User Manual

1. Satisfy the requirements of the API classification.
2. Have the proper SAE grade number for expected ambient temperature range.
CHANGE ENGINE OIL
1. Run the engine until it reaches normal operating temperature.
2. Turn off the engine.
3. Remove the oil filler cap and oil filter and then drain plug.
Drain the engine oil.
4. Tighten the drain plug to the specified torque.
Tightening torque
Oil pan drain plug :
35 ~ 45Nm (350 ~ 450kg.cm, 25 ~ 33lb.ft)
Whenever tightening the oil drain plug, use a new drain plug gasket.
5. Fill the new engine oil through the oil filler cap.
Drain and Refill
Oil quantity : 4.5lit (4.74U.S.qts., 3.95lmp.qts.)
Page
6
of
12
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...

Hyundai Tiburon 2003 Specifications

General

Brand	Hyundai
Model	Tiburon 2003
Category	Automobile
Language	English
