The auto light control system operates by using the auto light switch and the auto light sensor detect the
illumination then turns the head lamp and tail lamp on or off automatically in accordance with the detection
illumination.
SPECIFICATIONS
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > Auto Lighting Control System >
Description and Operation, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > Auto
Lighting Control System > Description and Operation
DESCRIPTION
Items Specifications
Rated voltage DC 5V
Operating current Max. 1mA
Detection illumination
Tail lamp
ON : 23.1 ± 3.4 (Lux), 1.77 ± 0.08 (V)
OFF : 48.0 ± 3.4 (Lux), 3.47 ± 0.10 (V)
Head lamp
ON : 6.2 ± 1.4 (Lux), 0.63 ± 0.06 (V)
OFF : 12.0 ± 1.4 (Lux), 1.02 ± 0.06 (V)
