Engine coolant temperature : 80~95°C (176~205°F)
discontinued.
Battery voltage Normal condition
When applied Vacuum is released
When discontinued Vacuum is maintained
5. Measure the current between the terminals of the solenoid valve.
EVAP Canister Purge Solenoid Valve
Coil at 20°C (68°F) : 0.45A or below (at 12V)
Coil resistance : 26Ω [at 20°C (68°F)]
VACUUM HOSE
1. Disconnect the vacuum hose from the intake manifold purge hose nipple and connect a hand vacuum pump to the
nipple.
2. Start the engine and check that, after raising the engine speed by racing the engine, vacuum remains fairly constant.
If there is no vacuum created the intake manifold port may be clogged and require cleaning.
Page
2
of
3
24.04.2008
http://www.hmaservice.com/viewer/content.asp?IsPrint=true&imgnum=1&print_title
...
