- TC valve relief pressure
O.D = Outer Diameter
I.D = Inner Diameter
CBS = Conventional Brake System
ABS = Anti-lock Brake System
TC Valve = Traction Control Valve
SERVICE STANDARD
Standard value Service limit
Brake pedal height 170 mm (6.69 in.)
Brake pedal stroke 128 mm (5.04 in.)
Stop lamp switch outer case to pedal stopper
clearance
0.5~1.0 mm (0.02~0.04
in.)
Brake pedal free play 3~8 mm (0.11~0.31 in.)
Brake pedal to floorboard clearance 61 mm (2.40 in.) or more
Booster push rod to master cylinder piston clearance 0 (at 500 mmHg vacuum)
Parking brake lever stroke when lever assembly is
pulled with 196N (20kg, 44lb force)
6~7 clicks
Front disc brake pad thickness 11 mm (0.43 in.) 2 mm (0.079 in.)
Front disc thickness (minimum ) 26 mm (1.02 in.) 22.4 mm (0.96 in.)
Rear disc brake pad thickness 9 mm (0.35 in.) 2 mm (0.08 in.)
Rear disc thickness 10 mm (0.4 in.) 8 mm (0.315 in.)
TIGHTENING TORQUE
Nm Kgf·cm lbf·ft
Master cylinder to booster mounting nut 8~12 80~120 6~9
Brake booster mounting nut 13~16 130~160 9.6~11.8
Brake booster vacuum hose fitting to surge tank 15~18 150~180 11.1~13.3
Bleeder screw 7~13 70~130 5.2~9.6
Brake tube flare nut, brake hose 13~17 130~170 9.6~12
Caliper guide rod bolt 22~32 220~320 16.2~23.6
Caliper assembly to knuckle 65~75 650~750 48~55
Brake hose to front caliper 25~30 250~300 18~22
Wheel speed sensor mounting bolt 8~9 80~90 6~7
Hydraulic & electronic control unit mounting bolt 8~10 80~100 6~7.4
Hydraulic & electronic control unit mounting bracket bolt 17~26 170~260 13~19
Replace self-locking nuts with new ones after removal.
