TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Steering System > Hydraulic Power Steering System > Power
Steering Gear Box > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Steering System >
Hydraulic Power Steering System > Power Steering Gear Box > Repair procedures
1. Detach the power steering pressure hose mounting clamp and the return tube mounting clamp.
2. Drain the power steering fluid.
3. Disconnect the pressure tube and the return tube fittings from the gear box.
4. Disconnect the shaft assembly from the gear box inside the passenger compartment.
5. Remove the strap and push out the dust cover and remove the dust cover mounting plate.
6. Raise up the vehicle.
7. Remove the front tires (RH/LH).
8. After removing the split pin, disconnect the tie rod from the knuckle by using the special tool (09568-31000).
9. Remove the stabilizer bar (RH side) mounting bracket and link nut.
10. After removing the rear roll stopper bracket mounting bolt from the sub frame, remove the rear roll stopper.
To Next Page
