Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body (Interior and Exterior) > Sun Roof > sun roof moter >
Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body (Interior and Exterior) > Sun Roof >
sun roof moter > Repair procedures
INSPECTION
1. Pull down the rear headliner.
2. Disconnect the motor side connector from the sunroof controller.
Remove the sunroof motor after removing 3 screws.
3. Connect the positive (+) lead from the battery to terminal 2 and the nagative (-) lead to terminal 1, check that
the motor turns counterclockwise (moves toward the close and down position).
4. Reverse the polarity, check that the motor turns clockwise (moves toward the up and open position).
If operation is not as specified, replace the motor.
