Hyundai Tiburon 2003 User Manual

TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Steering System > Hydraulic Power Steering System > Power
Steering Hoses > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Steering System >
Hydraulic Power Steering System > Power Steering Hoses > Repair procedures
REMOVAL AND INSTALLATION
PRESSURE HOSE AND TUBE
1. After draining the power steering fluid, remove the pressure hose mounting clamp.
2. Lift up the vehicle and remove the mounting clamp which is holding both the pressure tube and the return
tube.
3. Detach the pressure tube fitting in the gear box.
4. Lower the vehicle and remove the connector.
5. Remove the pressure hose and tube assembly.
6. Installation is the reverse of removal.
